LKN02 Butterfly Chest Expansion Trainer

2024 - 12 - 25

Product Dimensions:
Product Dimensions:1020 × 715 × 1280 mm
Packing Dimensions:1120 × 740 × 430 mm
Net/Gross Weight:46 kg / 52 kg
Maximum Load:*150 kg
Volume:** 0.6 m³
Technical Parameters:
Material: Q235 steel, 40802.5t oval tube, φ50*2.5t round tube
Coating: Electrostatic spray coating in white, black, silver-gray, with custom color options
Welding: Equipment uses integrated welding technology
Seat Cushion: Multi-layer PVC leather with foam process for contact areas, available in orange, blue, or custom colors
Exercise Principle: Hydraulic cylinder cycle principle
Hydraulic Resistance Mode: 6, 8, 10, or 12 levels (optional)
Testing Report: Complies with GB17498.1-2019 inspection standards
Oil Cylinder:
Hydraulic Cylinder: Bidirectional rebound
Stroke: 220 mm
Resistance Value:
1st Level: 84N
2nd Level: 130N
3rd Level: 251N
4th Level: 527N
5th Level: 939N
6th Level: 1453N
12th Level: 2000N
Usage Instructions:
"First, adjust the hydraulic cylinder knob to set the resistance to a level that suits you. After sitting on the equipment, ensure your back is against the backrest. Slowly move your arms inward and perform a smooth, rhythmic motion back and forth."
Specific Functions:

1. Improve joint mobility and prevent or delay muscle atrophy.
2. Increase muscle strength in the affected limb and reduce abnormal muscle tension.
3. Provide targeted training for specific muscles, enhance venous return, and prevent deep vein thrombosis in the lower limbs.
4. Enhance muscle strength, improve joint mobility, relieve muscle tension, and strengthen joint stability.
5. Promote the recovery of proprioceptive senses.

Features:

1. Reduce the likelihood of overload injuries.
2. Adjust according to the patient's pain and fatigue levels.
3. Provide multiple speed options for testing and training.
4. Reduce swelling caused by tremors.
5. Decrease pressure on joints as the movement speed increases.

Exercised Muscle Groups:Pectoralis Major、Triceps、Deltoid.
Solutions:Fitness、Weight loss Body、shapingHealth、improvement
Target Audience:
People with the purpose of fitness, weight loss, and health improvement.
Especially suitable for middle-aged and elderly individuals, particularly women.
